Volkswagen 2.0 TDI CSL Family (CSLA / CSLB / CSLC) – Engine Overview
The CSL engine family—consisting of CSLA, CSLB, and CSLC—is a 2.0-liter four-cylinder turbo-diesel range used in the Volkswagen Crafter (2E, 2F) platform. All versions share the same 1968 cc displacement and modern common-rail fuel system but differ in overall power output.
These engines were designed for commercial-duty applications, providing reliable low-end torque, strong fuel efficiency, and long service life, making them a popular choice for cargo vans, chassis cabs, minibuses, and various Crafter-based conversions. Depending on the year and emission configuration, these engines meet Euro 5 or Euro 6 standards.
Key Specifications
-
Engine codes: CSLA, CSLB, CSLC
-
Displacement: 1968 cc
-
Power output:
-
CSLA – 80 kW
-
CSLB – 84 kW
-
CSLC – 103 kW
-
-
Injection system: Common-rail direct injection
-
Turbocharger: Single turbocharger
-
Emission standard: Euro 5 / Euro 6 (variant-dependent)
-
Primary application: Volkswagen Crafter (2E, 2F)
Compatibility Table – VW Crafter Models Using CSLA / CSLB / CSLC
| Vehicle Type | Engine Code | Displacement | Power | Model Years |
|---|---|---|---|---|
| VOLKSWAGEN Crafter (2E, 2F) CR30 2.0 TDI | CSLB | 1968 cc | 84 kW | 2013–2016 |
| VOLKSWAGEN Crafter (2E, 2F) CR30 2.0 TDI | CSLC | 1968 cc | 103 kW | 2015–2016 |
| VOLKSWAGEN Crafter (2E, 2F) CR30 2.0 TDI | CSLA | 1968 cc | 80 kW | 2015–2016 |
| VOLKSWAGEN Crafter (2E, 2F) CR32 2.0 TDI | CSLB | 1968 cc | 84 kW | 2013–2016 |
| VOLKSWAGEN Crafter (2E, 2F) CR35 2.0 TDI | CSLA | 1968 cc | 80 kW | 2011–2016 |
| VOLKSWAGEN Crafter (2E, 2F) CR35 2.0 TDI | CSLB | 1968 cc | 84 kW | 2013–2016 |
| VOLKSWAGEN Crafter (2E, 2F) CR35 2.0 TDI | CSLC | 1968 cc | 103 kW | 2015–2016 |
| VOLKSWAGEN Crafter (2E, 2F) CR50 2.0 TDI | CSLB | 1968 cc | 84 kW | 2013–2016 |
Conclusion
The CSLA, CSLB, and CSLC engines represent some of the most reliable and efficient diesel options in the Volkswagen Crafter lineup. With proven performance, solid low-RPM torque, and compatibility across multiple Crafter body types and weight classes, these engines remain a trusted choice for commercial operators and vehicle converters. Whether used for cargo transport, fleet service, or camper builds, the CSL engine family delivers durability, economical operation, and long-term value.
